How to Program
2 2
2.4 Quick Transfer of Parameter Settings
between Multiple Adjustable Frequency
Drives
Once the set-up of an adjustable frequency drive is
complete, Danfoss recommends that you store the data in
the LCP or on a PC via MCT-10 Setup Software tool.
Data storage in LCP.
WARNING
Stop the motor before performing this operation.
1. Go to 0-50 LCP Copy
2. Press the [OK] key
3. Select "All to LCP"
4. Press the [OK] key
Connect the LCP to another adjustable frequency drive
and copy the parameter settings to this adjustable
frequency drive as well.
Data transfer from LCP to adjustable frequency drive:
NOTE!
Stop the motor before performing this operation.
1. Go to 0-50 LCP Copy
2. Press the [OK] key
3. Select "All from LCP".
4. Press the [OK] key
2.5 Read-out and Programming of Indexed
Parameters
Use as an example.
Choose the parameter, press [OK], and use [
through the indexed values. To change the parameter
value, select the indexed value and press [OK]. Change the
value by using the up/down keys. Press [OK] to accept the
new setting. Press [Cancel] to abort. Press [Back] to leave
the parameter.
2-12
®
VLT HVAC Basic Drive Programming Guide
2.6 Initialize the Adjustable Frequency
Drive to Default Settings in Two Ways
Recommended initialization (via 14-22 Operation Mode)
1.
2.
3.
4.
5.
▲ ▼
/ ] to scroll
Two-finger initialization:
1.
2.
3.
4.
®
MG18B222 - VLT is a registered Danfoss trademark
Select 14-22 Operation Mode.
Press [OK].
Select Initialization and Press [OK].
Cut off the line power supply and wait until the
display turns off.
Reconnect the line power supply - the adjustable
frequency drive is now reset. Except the following
parameters.
8-30 Protocol
8-31 Address
8-32 Baud Rate
8-33 Parity / Stop Bits
8-35 Minimum Response Delay
8-36 Maximum Response Delay
8-37 Maximum Inter-char delay
8-70 BACnet Device Instance
8-72 MS/TP Max Masters
8-73 MS/TP Max Info Frames
8-74 "I am" Service
8-75 Intialisation Password
15-00 Operating hours to 15-05 Over Volt's
15-03 Power Up's
15-04 Over Temp's
15-05 Over Volt's
15-30 Alarm Log: Error Code
15-4* Drive identification parameters
1-06 Clockwise Direction
Power off the adjustable frequency drive.
Press [OK] and [Menu].
Power up the adjustable frequency drive while
still pressing the keys above for 10 s.
The adjustable frequency drive is now reset,
except the following parameters:
