Parameter Lists

5.1.6 4-** Limits/Warnings

Par. Parameter description
No. #
4-1* Motor Limits
4-10 Motor Speed Direction
4-12 Motor Speed Low Limit [Hz]
4-14 Motor Speed High Limit [Hz]
5 5 4-18 Current Limit
4-19 Max Output Frequency
4-4* Adj. Warnings 2
4-40 Warning Freq. Low
4-41 Warning Freq. High
4-5* Adj. Warnings
4-50 Warning Current Low
4-51 Warning Current High
4-54 Warning Reference Low
4-55 Warning Reference High
4-56 Warning Feedback Low
4-57 Warning Feedback High
4-58 Missing Motor Phase Function
4-6* Speed Bypass
4-61 Bypass Speed From [Hz]
4-63 Bypass Speed To [Hz]
4-64 Semi-Auto Bypass Set-up
Table 5.7
5-6
®
VLT HVAC Basic Drive Programming Guide
Default value
[2] Both directions
0 Hz
65 Hz
110 %
ExpressionLimit
ExpressionLimit
ExpressionLimit
0 A
ExpressionLimit
-4999 N/A
4999 N/A
-4999 ProcessCtrlUnit
4999 ProcessCtrlUnit
[1] On
0 Hz
0 Hz
[0] Off
®
MG18B222 - VLT is a registered Danfoss trademark
2-set-up Change Conver-
during sion index
operation
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Type
- Uint8
-1 Uint16
-1 Uint16
0 Uint16
-1 Uint16
-1 uint16
-1 uint16
-2 Uint32
-2 Uint32
-3 Int32
-3 Int32
-3 Int32
-3 Int32
- Uint8
-1 Uint16
-1 Uint16
- Uint8
