Parameters
0-30 Custom Readout Unit
Option:
[124] CFM
3
3
[127] ft3/h
[140] ft/s
[141] ft/min
[160] Degree Fahr
[170] psi
[171] lb/in2
[172] in WG
[173] ft WG
[180] hp
0-31 Custom Readout Min Value
Range:
0 CustomRea-
doutUnit
*
0-32 Custom Readout Max Value
Range:
100 CustomRea-
doutUnit
*
0-37 Display Text 1
Range:
Function:
[0 - 0 ] In this parameter it is possible to write an individual
text string to be read via serial communication.
Only used when running BACnet.
0-38 Display Text 2
Range:
Function:
[0 - 0 ] In this parameter it is possible to write an individual
text string to be read via serial communication.
Only used when running BACnet.
0-39 Display Text 3
Range:
Function:
[0 - 0 ] In this parameter it is possible to write an individual
text string to be read via serial communication.
Only used when running BACnet.
3-4
VLT
Function:
Function:
[ 0 - 999999.99
This parameter allows the
CustomRea-
choice of the min. value of
doutUnit]
the custom defined readout
(occurs at zero speed). It is
only possible to select a value
different to 0 when selecting
a linear unit in 0-30 Custom
Readout Unit. For quadratic
and cubic units, the minimum
value will be 0.
Function:
[ 0.0 - 999999.99
This parameter sets the
CustomRea-
max value to be shown
doutUnit]
when the speed of the
motor has reached the set
value for 4-14 Motor Speed
High Limit [Hz].
MG18B222 - VLT
®
HVAC Basic Drive Programming Guide
3.1.4 0-4* LCP
Enable, disable and password protect individual keys on
the LCP.
0-40 [Hand on] Key on LCP
Option:
[0] Disabled Select [0] Disabled to avoid accidental start of the
[1] Enabled [Hand on] key is enabled.
0-42 [Auto on] Key on LCP
Option:
[0] Disabled Select [0] Disabled to avoid accidental start of the
[1] Enabled [Auto on] key is enabled.
0-44 [Off/Reset] Key on LCP
Option:
[0]
Disabled
[1]
Enabled
[7]
Enable Reset Only
3.1.5 0-5* Copy/Save
Copy parameter settings between set-ups and to/from the
LCP.
0-50 LCP Copy
Option:
[0] No copy
[1] All to LCP
[2] All from
LCP
[3] Size indep.
from LCP
®
is a registered Danfoss trademark
Function:
adjustable frequency drive in Hand mode.
Function:
adjustable frequency drive from LCP.
Function:
Function:
Copies all parameters in all set-ups from the
adjustable frequency drive memory to the LCP
memory. For service purposes, it is
recommended to copy all parameters to the
LCP after commissioning.
Copies all parameters in all set-ups from the
LCP memory to the adjustable frequency drive
memory.
Copies only the parameters that are
independent of the motor size. The latter
selection can be used to program several
adjustable frequency drives with the same
function without disturbing motor data that are
already set.
