Parameters
5-11 Terminal 19 Digital Input
Parameter for configuring the input function on input terminal
19.
Option:
[52] Run permissive
[53] Hand start
[54] Auto start
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
5-12 Terminal 27 Digital Input
Parameter for configuring the input function on input terminal
27.
Option:
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inverse
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[7] External Interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[34] Ramp bit 0
[37] Fire Mode
[52] Run permissive
[53] Hand start
[54] Auto start
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
®
VLT HVAC Basic Drive Programming Guide
5-13 Terminal 29 Digital Input
Parameter for configuring the input function on input terminal
29.
Function: Option:
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[14]
Function:
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[23]
[32]
[34]
[37]
[52]
[53]
[54]
[60]
[61]
[62]
[63]
[64]
[65]
®
MG18B222 - VLT is a registered Danfoss trademark
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC-brake inverse
Stop inverse
External Interlock
Start
Latched start
Reversing
Start reversing
Jog
Preset ref bit 0
Preset ref bit 1
Preset ref bit 2
Freeze reference
Freeze output
Speed up
Speed down
Set-up select bit 0
Pulse input
Ramp bit 0
Fire Mode
Run permissive
Hand start
Auto start
Counter A (up)
Counter A (down)
Reset Counter A
Counter B (up)
Counter B (down)
Reset Counter B
3 3
