Danfoss VLT HVAC Basic Drive FC 100 Series Programming Manual page 61

Parameters
6-71 Terminal 45 Analog Output
Option: Function:
Select the function of Terminal 45 as an
analog current output. See also
6-70 Terminal 45 Mode.
[0] No operation
[100] Output frequency 0–100 Hz
[101] Reference MinRef. - MaxRef.
[102] Feedback MinFB - MaxFB
[103] Motor Current 0-I
max
[106] Power 0-P
nom
[139] Bus Control 0–100%
6-72 Terminal 45 Digital Output
Option:
[0] No operation
[1] Control Ready
[2] Drive ready
[3] Drive ready/remote control
[4] Standby / no warning
[5] Drive running
[6] Running / no warning
[7] Run in range/no warning
[8] Run on ref/no warning
[9] Alarm
[10] Alarm or warning
[12] Out of current range
[13] Below current, low
[14] Above current, high
[16] Below speed, low
[17] Above speed, high
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[22] Ready, no thermal warning
[23] Remote, ready, no thermal warning
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[35] External Interlock
[36] Control word bit 11
[37] Control word bit 12
®
VLT HVAC Basic Drive Programming Guide
6-72 Terminal 45 Digital Output
Option:
[41]
[42]
[45]
[60]
[61]
[62]
[63]
[64]
[65]
[70]
[71]
[72]
[73]
[74]
Function:
[75]
Select the function of
[80]
Terminal 45 as a
[81]
digital current output.
[82]
See also 6-70 Terminal
[83]
45 Mode. See
[160] No alarm
5-40 Function Relay for
[161] Running reverse
description of the
[165] Local ref. active
choices.
[166] Remote ref. active
[167] Start command activ
[168] Drive in hand mode
[169] Drive in auto mode
[193] Sleep Mode
[194] Broken Belt Function
[196] Fire Mode
[198] Drive Bypass
6-73 Terminal 45 Output Min Scale
Range:
0 %
6-74 Terminal 45 Output Max Scale
Range:
100 %
6-76 Terminal 45 Output Bus Control
Range:
0
®
MG18B222 - VLT is a registered Danfoss trademark
Below reference, low
Above ref, high
Bus Control
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Comparator 4
Comparator 5
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Logic rule 4
Logic rule 5
SL digital output A
SL digital output B
SL digital output C
SL digital output D
[0 - 200 %]
*
[0 - 200 %]
*
[0 - 16384 ]
*
Function:
3
Function:
Function:
Function:
3-33
3
