How to Program
No & Name
2 2
6-10 Terminal 53 Low
Voltage
6-11 Terminal 53 High
Voltage
6-12 Terminal 53 Low
Current
6-13 Terminal 53 High
Current
6-19 Terminal 53 mode
Table 2.4
2-6
®
VLT HVAC Basic Drive Programming Guide
Range
0–10 V
0–10 V
0-20 mA
0-20 mA
[0] Current
[1] Voltage
MG18B222 - VLT
Default Function
0.07 V Enter the voltage that corresponds to the low
reference value.
10 V Enter the voltage that corresponds to the high
reference value.
4 Enter the current that corresponds to the low
reference value.
20 Enter the current that corresponds to the high
reference value.
1 Select if terminal 53 is used for current or voltage
input.
®
