Parameters
13-51 SL Controller Event
Array [20]
Option: Function:
[74] SL Time-out 7
[83] Broken Belt
13-52 SL Controller Action
Array [20]
Option: Function:
Select the action corresponding to the
SLC event. Actions are executed when
the corresponding event (defined in
13-51 SL Controller Event) is evaluated as
true. The following actions are available
for selection:
[0] Disabled
[1] No action
[2] Select set-up 1 Changes the active set-up (0-10 Active
Set-up) to '1'.
[3] Select set-up 2 Changes the active set-up (0-10 Active
Set-up) to '2'.
[10] Select preset ref Selects preset reference 0.
0
[11] Select preset ref Selects preset reference 1.
1
[12] Select preset ref Selects preset reference 2.
2
[13] Select preset ref Selects preset reference 3.
3
[14] Select preset ref Selects preset reference 4.
4
[15] Select preset ref Selects preset reference 5.
5
[16] Select preset ref Selects preset reference 6.
6
[17] Select preset ref Selects preset reference 7. If the active
7 preset reference is changed, it will
merge with other preset reference
commands coming from either the
digital inputs or via a serial communi-
cation bus.
[18] Select ramp 1 Selects ramp 1
[19] Select ramp 2 Selects ramp 2
[22] Run Issues a start command to the
adjustable frequency drive.
[23] Run reverse Issues a start reverse command to the
adjustable frequency drive.
[24] Stop Issues a stop command to the
adjustable frequency drive.
®
VLT HVAC Basic Drive Programming Guide
13-52 SL Controller Action
Array [20]
Option:
[25] Qstop
[26] DC Brake
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set digital out A
[33] Set digital out B
[34] Set digital out C
[35] Set digital out D
[38] Set digital out A
[39] Set digital out B
[40] Set digital out C
[41] Set digital out D
[60] Reset Counter A
[61] Reset Counter B
[70] Start Timer 3
[71] Start Timer 4
[72] Start Timer 5
[73] Start Timer 6
®
MG18B222 - VLT is a registered Danfoss trademark
Function:
Issues a quick stop command to the
adjustable frequency drive.
Issues a DC stop command to the
adjustable frequency drive.
The adjustable frequency drive coasts
immediately. All stop commands
including the coast command stop the
SLC.
Freezes the output frequency of the
adjustable frequency drive.
Starts timer 0, see 13-20 SL Controller
Timer for further description.
Starts timer 1, see 13-20 SL Controller
Timer for further description.
Starts timer 2, see 13-20 SL Controller
Timer for further description.
Any output with 'digital output 1'
low selected is low (off).
Any output with 'digital output 2'
low selected is low (off).
Any output with 'digital output 3'
low selected is low (off).
Any output with 'digital output 4'
low selected is low (off).
Any output with 'digital output 1'
high selected is high (closed).
Any output with 'digital output 2'
high selected is high (closed).
Any output with 'digital output 3'
high selected is high (closed).
Any output with 'digital output 4'
high selected is high (closed).
Resets Counter A to zero.
Resets Counter B to zero.
Starts timer 3, see 13-20 SL Controller
Timer for further description.
Starts timer 4, see 13-20 SL Controller
Timer for further description.
Starts timer 5, see 13-20 SL Controller
Timer for further description.
Starts timer 6, see 13-20 SL Controller
Timer for further description.
