Parameters
13-01 Start Event
Option: Function:
[23] Comparator 1 Use the result of comparator 1 in the
logic rule.
[24] Comparator 2 Use the result of comparator 2 in the
logic rule.
[25] Comparator 3 Use the result of comparator 3 in the
logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the logic
rule.
[27] Logic rule 1 Use the result of logic rule 1 in the logic
rule.
[28] Logic rule 2 Use the result of logic rule 2 in the logic
rule.
[29] Logic rule 3 Use the result of logic rule 3 in the logic
rule.
[33] Digital input Use the value of DI18 in the logic rule
DI18 (High = TRUE).
[34] Digital input Use the value of DI19 in the logic rule
DI19 (High = TRUE).
[35] Digital input Use the value of DI27 in the logic rule
DI27 (High = TRUE).
[36] Digital input Use the value of DI29 in the logic rule
DI29 (High = TRUE).
[39] Start command This event is TRUE if the adjustable
frequency drive is started by any means
(either via digital input, serial communi-
cation bus or other).
[40] Drive stopped This event is TRUE if the adjustable
frequency drive is stopped or coasted by
any means (either via digital input, serial
communication bus or other).
[42] Auto Reset Trip This event is TRUE if the adjustable
frequency drive is tripped (but not trip-
locked) and an automatic reset is issued.
[50] Comparator 4 Use the result of comparator 4 in the
logic rule.
[51] Comparator 5 Use the result of comparator 5 in the
logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the logic
rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic
rule.
[83] Broken Belt A broken belt condition has been
detected. This function must be enabled
in 22-60 Broken Belt Function.
®
VLT HVAC Basic Drive Programming Guide
13-02 Stop Event
Option:
[0]
[1]
[2]
[3]
[4]
[7]
[8]
[9]
[16] Thermal warning
[17] Mains out of
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
®
MG18B222 - VLT is a registered Danfoss trademark
Function:
Select the condition (TRUE or FALSE)
which will deactivate the Smart Logic
Controller.
False Enters the fixed value of FALSE in the
logic rule.
True Enters the fixed value TRUE in the logic
rule.
Running See 13-01 Start Event for further
description.
In range See 13-01 Start Event for further
description.
On reference See 13-01 Start Event for further
description.
Out of current See 13-01 Start Event for further
range description.
Below I low See 13-01 Start Event for further
description.
Above I high See 13-01 Start Event for further
description.
See 13-01 Start Event for further
description.
See 13-01 Start Event for further
range description.
See 13-01 Start Event for further
description.
See 13-01 Start Event for further
description.
See 13-01 Start Event for further
description.
See 13-01 Start Event for further
description.
Use the result of comparator 0 in the
logic rule.
Use the result of comparator 1 in the
logic rule.
Use the result of comparator 2 in the
logic rule.
Use the result of comparator 3 in the
logic rule.
Use the result of logic rule 0 in the
logic rule.
Use the result of logic rule 1 in the
logic rule.
3 3
3-41
