1237 G76 screw thread fine processing circles
exceed 2000
1238 G76 circle processing start is lower than
the end position of the screw thread
1239 The arc radius exceeds allowable error
1240 G94 hasn't specified axis X coordinates
1244 T code format error
1245 S code format error
1246 Exceed IO port number
1247 M88/M89 hasn't specified port number
1248 G71 rough circle knife forward error
1249 G71, G72 or G73 profile description
contains incompatible G code or M code
1250 G72 rough circle knife forward error
1251 G73 axis X rough reserve volume is
negative
1252 G73 axis Z rough reserve volume is
negative
1253 G74- axis Z end isn't specified or
movement is 0
1254 G74- axis Z knife forward is 0 or exceeds
allowable range
1255 G74- radial offset exceeds allowable
range
1256 G74- radial knife backward exceeds
allowable range
1257 G75 axis X end isn't specified or
movement is 0
Alarm code
1258 G75 - axis Z offset exceeds allowable
range
1259 G75 - radial knife forward is 0 or exceeds
allowable range
1260 G75 - axial knife backward exceeds
allowable range
1261 G76 minimum rough knife forward is 0
1262 G76 circle doesn't specify the end
coordinates of screw thread
1263 G76 circle doesn't specify the height of
screw thread
1264 G76 circle doesn't specify the pitch of
screw thread
1265 G90, G92, G94 program error, R value
exceeds allowable range
1266 G28 instruction format error
1267 G7X start line number isn't found
1268 G7X code format error or emergency stop
during motion
1270 G7X circle doesn't support auxiliary
function
1271 The first program section of G7X profile
description is arc
1272 One program section doesn't support
multiple M codes
1273 G71 G72 G73 start position error
1274 G71 G72 fine allowance can't exceed
rough knife forward
1275 Screw thread speed exceeds maximum Reduce the main axis rotation
CNC 4 2 2 0 M a c hi ne Too l Op e ra t ion an d Te st
Content
Check and modify the program to reduce the circles
Please modify the start position of circle processing
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Solution
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
Check and modify the program
