13.9.2 PARAMETER SETTINGS

Set the tailstock control to "1" to activate the tailstock function, or set it to "0" to deactivate the
function.
Note: Do not push the tailstock forward/backward when the main axis is rotating, or else the alarm
occurs.

13.10. Knife replacing control

13.10.1 WIRING DIAGRAM OF ELECTRIC KNIFE RACK

Knife position hall elements T01-T08
