5) To edit the program content, please input the address and then the number (If the program
section contains several instruction words, please input all instruction words in the above
mentioned method), and then press the Insert key
section. (If the input buffer contains the input characters, press the
insert the data in buffer and start a new line. If it is in the line, please edit current instructions.)
Press the
6) Input other sections of the program in the method in step 5.

6.1.2 SEARCHING INSTRUCTIONS WORDS

◆Scanning: the cursor scans every instruction word in sequence
1) Press the
Press the
key, the cursor moves downwards by instruction word consecutively; press the Up/Down key,
the cursor moves in opposite direction.
Program
Data=
key and the cursor goes to the program section in next line.
key, and the cursor moves upwards or downwards by instruction word.
key once, the cursor moves to next instruction word; press and hold the
Program
Data=
CNC 4 2 2 0 M a c hi ne Too l Op e ra t ion an d Te st
MDI mode
to complete the input of the program
MDI mode
key at the line end to
29
