1.5.6 ALARM INTERFACE
When the system alarms, press the Diagnosis key
alarm information.
Settings interface
The Setting key
1.5.7 SETTINGS INTERFACE
The settings interface contains two pages, and you can press the Up/Down key
view.
Parameter switch: when the parameter switch is on, you can edit the parameters; when it is off,
you can't edit; press the
Program switch: when the program switch is on, you can edit the program; when it is off, you
can't edit; press the
Alarm info
41-Main axis control logical error
Alarm
is composite, and you can press it repeatedly to switch the setting/graph interface.
Settings
Parameter switch (W):
Program switch (H):
key to switch the state in MDI mode
key to switch the state in MDI mode
CNC 4 2 2 0 M a c hi ne Too l Op e ra t ion an d Te st
to enter the alarm interface and view the
Manual mode
Fig. 1-3-10
OFF
ON
OFF
ON
Manual mode
Fig. 1-3-12
to
16
