1.5.11 PARAMETER INTERFACE

Press the Parameter key
data parameters. You can press the Up/Down key
the prompt line of parameter contents displays the contents of the parameter that the cursor points
to. The parameters can be edited in MDI mode. Input the target parameter number and press the
EOB key to go to the specified parameters.
Parameter settings
1. Axis X instruction magnification
2. Axis X instruction frequency conversion coefficient
3. Axis Z instruction magnification
4. Axis Z instruction frequency conversion coefficient
5. Feeding speed
6. Start feeding speed
7. Feeding acceleration time
1. Axis X instruction magnification

1.5.12 DIAGNOSIS INTERFACE

The Diagnosis key
diagnosis interface and machine tool panel interface.
Diagnosis interface display
Press the Up/Down key
diagnosis display system and machine tool
Input point status interface
CNC 4 2 2 0 M a c hi ne Too l Op e ra t ion an d Te st
to enter the interface, which consists of system parameters and
System parameters Page 1
Fig. 1-3-15
is composite, and you can press it repeatedly to switch between
to view the I/O signal state and system state of the
Input point state
to view. In parameters display page,
Manual mode
(mm/min)
(mm/min)
(mm/min)
