1.2. Display menus

Menu keys
Position
Program
Knife
compensation
Settings
Parameters
Diagnosis
1.3. Machine tool panel
The keys are described in the table below:
Keys
Pause
Start
CNC 4 2 2 0 M a c hi ne Too l Op e ra t ion an d Te st
Input the end symbol of program segment, or
EOB key
edit the option
Control the moving of cursor in program
editing mode and parameter interface
Cursor
Adjust the feeding and magnification quickly
moving
in auto mode
keys
Single step mode: Adjust the increment in
single step
Page
turning Turn pages in same display mode
keys
Enter the position interface, which consists of relative
coordinate, absolute coordinate, comprehensive coordinate,
and position/program.
Enter the program interface, which consists of program, MDI
and program directory.
Enter knife bias interface, which includes knife compensation
data and macro variable
Enter the setting interface and graph interface (press
repeatedly to switch); the setting interface includes code
setting and switch setting; the graph interface includes graph
parameters and graph display
Enter the parameter interface, display the system parameters
View alarm info when there is alarm
Enter the diagnosis interface and machine tool panel (press
repeatedly to switch); the diagnosis interface and diagnosis
parameters; the soft keypad operation can be performed on the
machine tool panel
Name
Feeding
maintaining key
Loop start key
Remark
Function description
Pause program, MDI instruction
running
Start program,
running
MDI instruction
