See the description in
Section 1.1, and the
value varies
according to
selection

4.2. Increment selection

Press the
press the key to change the increment to 0.1, and press it again to change the increment to 1. To
reduce the increment, press the

4.3. Motion direction selection

Press the
or positive direction; press the
increment in negative or positive direction.

4.4. Handwheel feeding

Press the Single step
below:
Current position (absolute coordinates)
the
Single step
increment:
key to adjust the increment of single step: if the current increment is 0.01,
key.
or key once to feed once the axis X in single step increment in negative
key to enter handwheel operation mode, which is shown in the figure
CNC 4 2 2 0 M a c hi ne Too l Op e ra t ion an d Te st
G code:
Processing pieces:
Cutting time:
Single step mode
Fig. 4-1-1
or key once to feed once the axis Z in single step
25
