Alarm Info Reference Table - Adtech ADT-CNC4220 User Manual

99 Serial port baud rate
100 G74 axial knife backward
101 G74 radial offset
102 G74 axial knife forward
103 G74 radial knife backward
104 G75 radial knife backward
105 G75 axial offset
106 G75 radial knife forward
107 G75 axial knife backward
108 G71 rough knife forward
109 G71 rough knife backward
110 G71 axis X fine allowance
111 G71 axis Z fine allowance
112 G72 rough knife forward
113 G72 rough knife backward
114 G72 axis X fine allowance
115 G72 axis Z fine allowance
116 G73 axis X rough allowance
117 G73 axis Z rough allowance
118 G73 axis X fine allowance
119 G73 axis Z fine allowance
120 G73 cycles
121 System language
122 Screw thread acceleration/
deceleration mode

13.17. Alarm info reference table

Alarm code
1000 Please reset
1001 File format error occurs when copying
files
1002 Serial communication: memory is full
1003 Serial communication: data overlength
1004 Serial communication: no filename
1005 Serial communication: no file end
1006 Serial communication: system data is full
1007 Serial communication: data receiving
successfully
1008 Serial communication: file of same name
exists
1009 Serial communication: file saved
1010 Files exceed 9999 in the system
1011 File of same name exists
1012 File copy successfully
1013 Parameter switch ON
1014 Program switch OFF
1015 Parameter switch OFF
1016 Parameter switch disabled
1017 Program switch disabled
1018 The numerator or denominator of the
electronic gear ratio exceeds 9999
1019 MDI running doesn't support G code
1020 MDI running doesn't support M code
1021 Password error
1022 Didn't set the program origin with G50
1023 Knife replacing fails
CNC 4 2 2 0 M a c hi ne Too l Op e ra t ion an d Te st
115200
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
-9999-9999
1-9999
1-255
0-1
Content
115200
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
Solution
Press the Reset key
Check the file format and modify the file
Delete some files
Check whether the file size exceeds the device
memory
Check the file format and modify the file
Check the file format and modify the file
Delete some files
Send in another file name
Delete some files
Copy in another file name
Turn on program switch
Turn on parameter switch
Modify system parameter ——parameter switch
Modify system parameter ——program switch
Modify the numerator or denominator of the
electronic gear ratio
Modify the program
Modify the program
Please enter the password below
Please set and return to program origin
Check the parameters and lines
89
