electric impact to the equipment;
Note 3: After relieving the alarm, please re-execute the mechanical reset operation to ensure
the accuracy of the coordinates (if the machine tool doesn't have mechanical origin, do
not perform this operation);
Note 4: The function is valid only when the value is set to 1.

8.1.3 AUTOMATIC RUNNING IN ANY SECTION

Under certain conditions, it is necessary to start running from a line in the processing program.
This system allows starting running from any section of current program. The specific operation
follows:
A. Press the Edit
program display page, and then press the Auto key
B. Move the cursor to the program section to start running (for example, to start running from N0050,
move the cursor to instruction word N0050);
C. Move the knife to the end position after the previous program section of the current program
section has run.
D. If the current mode state isn't consistent to the mode state before running this program section,
please perform the corresponding mode function and state;
E. Press the Start key

8.1.4 FEEDING MAGNIFICATION REGULATION

During automatic running, you can change the running speed by regulating the feeding
magnification in this system, and don't need to change the speed set in the program and
parameters.
CNC 4 2 2 0 M a c hi ne Too l Op e ra t ion an d Te st
key to enter the editing mode, press the Program key
Program
Data=
to start the program.
to enter the auto mode;
Manual mode
to enter the
43
