Installation
6.3
Installation in Vacon® 20
6.3.1
Frames MI1, MI2, MI3
Remove the cable connector lid from the
AC drive.
1
2
3
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
Select a correct grounding plate and attach it to the
option board mounting frame. The grounding plate is
marked with the supported enclosure size.
11649_00
Attach an option board mounting frame to
the AC drive.
11556A_0
vacon • 43
11555A_00
6
