Installation
Install the option board into the correct slot, D or E.
3
Close the option board cover.
4
Remove the cable entry plate. If you
installed the option board in the slot
D, use the cable entry plate on the
right side. If you installed the option
board in the slot E, use the cable en-
try plate on the left side.
5
NOTE! The cable entry plate at the
bottom of the drive is used only for
mains and motor cables.
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
D
vacon • 53
E
11640_00
11641_00
6
