vacon • 44
Connect the flat cable from the option board mounting frame to V20.
4
If a cable strain relief is required, attach the parts as shown in the figure.
5
Install the option board to the option board
holder. Make sure that the option board is
securely fastened.
6
6
11557A_00
11558A_00
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
Installation
11559A_00
