vacon • 46
6.3.2
Frames MI4, MI5
Make sure power is disconnected before opening the V20 cover.
13006.emf
1a: For MI4: Open the cover.
1
1b: For MI5: Open the cover and release the fan connector.
Attach the option board support.
2
6
11561_00
11562_00
11563_00
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
Installation
