Installation
Connect the flex cable to option board connector PCB.
3
Connect the option board to connector PCB.
4
Attach the option board with connector PCB to V20 and connect the flex cable.
5
Attach a suitable grounding plate to V20. The grounding plate is marked with sup-
ported enclosure size.
6
