vacon • 50
Remove the option slot cover.
2
Install the option board into the slot as shown in the figure.
3
Mount the option slot cover. Remove the plastic opening for the option board ter-
minals.
4
6
7089_00
7090_00
7091_00
7091_00
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
Installation
