FB Status Word Extension (general status word)

Mapped into FB PD out offset 1.
Table 94. FB Status word extension
15 14 13 12
CP3 CP2 CP1 -
Bit Name
15 CP3 Control Place
14 CP2
13 CP1
8.4.8

FB Actual Speed

Mapped into FB PD out offset 2.
Table 96. FB Actual Speed
15 14 13 12
Table 97. FB Actual Speed description
Name
FB Actual Speed Actual output frequency at percentage
between minimum and maximum frequency.
Status word bit DIR is used to indicate actual
8.4.9

FB Processdata Output 1...8

Mapped into FB PD out offset 3...11
Table 98. FB Process data output 1...8
15 14 13 12
8.4.10

FB Processdata Output mapping in application

Process data output mappings are selectable and also the default settings vary between drives. Re-
fer to application manual for details. The following tables show the default values for Vacon 100 IN-
DUSTRIAL application, Vacon 20 X Multipurpose Application and Vacon 20 Standard Application.
