4.2.3

Installing a TIM module as CP

Order of installation
Note
Only 1 DNP3 TIM module may be installed in an S7-300. This means that TIM modules of
other types cannot be added either.
Install a TIM as a CP in an S7-300 rack by following the steps in the order shown below:
1. Turn off the power supply to the CPU.
2. A bus module connector ships with the TIM. Insert this in the backplane connector of the
module to the left of the TIM.
3. If you want to install further modules to the right of the TIM, insert the bus module
connector of the next module into the right backplane connector of the TIM.
4. Place the TIM on the standard rail and push it in towards the bottom.
5. Screw the TIM securely into position.
6. Connect the TIM to the same power supply as the CPU.
7. If you are connecting the TIM to an external modem, the insert the 9-pin D-sub connector
of the modem connecting cable into the X1 (or X2) connector of the TIM and screw it
tight.
8. Turn on the power supply.
The TIM starts up. The LEDs indicate the current start-up activities (see separate section
Start-up activities
9. Once it has started up, the TIM can be supplied with its parameters (SDBs) using the
SINAUT diagnostics and service tool.
With the TIM 3V-IE DNP3 and the TIM 4R-IE DNP3, the SDBs can also be loaded on the
memory card of the S7-300 CPU, with the TIM 4R-IE DNP3, you can also use the
optional C-PLUG of this module for storage. The TIM receives then its configuration data
from the CPU during startup or takes it from the inserted C-PLUG.
4.2.4

Installing a TIM 4R-IE DNP3 as a standalone device

Order of installation
To install the TIM 4R-IE DNP3 as a standalone device on an S7-300 rail, follow the steps
below in the order shown:
1. Place the TIM on the standard rail and push it in towards the bottom.
2. Screw the TIM securely into position.
3. Connect the TIM to the power supply. Since this is a separate TIM rack, this does not
need to be the power supply of the CPU with which the TIM is connected via Ethernet.
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
).
Installation and commissioning
4.2 Mounting and connecting up a TIM
67
