Circuit Breakers; Mains Contactors - Danfoss VLT AQUA Drive FC 202 Design Manual

How to Install

5.5.2 Circuit Breakers

Frame Size Voltage [V]
D6h 380-480
D6h 380-480
D8h 380-480
D8h 380-480
D8h 380-480
D6h 525-690
D8h 525-690
D8h 525-690
Table 5.19 D-frame Circuit Breakers
Frame size Power & Voltage
P450 380-500 V & P630-P710
F3 525-690 V
P500-P630 380-500 V & P800
F3 525-690 V
P710 380-500 V & P900-P1M2
F4 525-690 V
F4 P800 380-500 V
Table 5.20 F-frame Circuit Breakers

5.5.3 Mains Contactors

Frame size
D6h
D8h
Table 5.21 D-frame Contactors
MG20Z202
Design Guide
Drive Model Circuit Breaker Type
N110 - N132 ABB T5L400TW
N160 ABB T5LQ400TW
N200 ABB T6L600TW
N250 ABB T6LQ600TW
N315 ABB T6LQ800TW
N75K - N160 ABB T5L400TW
N200 - N315 ABB T6L600TW
N400 ABB T6LQ600TW
Merlin Gerin NPJF36120U31AABSCYP
Merlin Gerin NRJF36200U31AABSCYP
Merlin Gerin NRJF36200U31AABSCYP
Merlin Gerin NRJF36250U31AABSCYP
Power & Voltage
N90K-N132 380-500 V
N110-N160 380-480 V
N55-N132 525-690 V
N75-N160 525-690 V
N160-N250 380-500 V
N200-N315 380-480 V
N160-N315 525-690 V
N200-N400 525-690 V
Danfoss A/S © Rev. 06/2014 All rights reserved.
Default breaker settings (Trip level -
I1 (Overload)
Type
Contactor
GE CK95CE311N
GE CK95BE311N
GE CK95CE311N
GE CK95BE311N
GE CK11CE311N
Amps)
I3/Ith (Instantaneous)
400 4000
400 4000
600 6000
600 6000
800 8000
400 4000
600 6000
600 6000
Default breaker settings
Trip level [A] Time [s]
1200 0.5
2000 0.5
2000 0.5
2500 0.5
131
5 5
