Selection

3.1.2 Digital Inputs - Terminal X30/1-4

Parameters for set-up: 5–16, 5–17 and 5–18
Number of
digital inputs
3 3
3
Table 3.1 Digital Inputs - Terminal X30/1-4

3.1.3 Analog Voltage Inputs - Terminal X30/10-12

Parameters for set-up: 6–3*, 6–4* and 16–76
Number of analog voltage inputs
2
Table 3.2 Analog Voltage Inputs - Terminal X30/10-12

3.1.4 Digital Outputs - Terminal X30/5-7

Parameters for set-up: 5–32 and 5–33
Number of digital outputs
2
Table 3.3 Digital Outputs - Terminal X30/5-7

3.1.5 Analog Outputs - Terminal X30/5+8

Parameters for set-up: 6–6* and 16–77
Number of analog outputs
1
Table 3.4 Analog Outputs - Terminal X30/5+8
42
Design Guide
Voltage level Voltage levels
0-24V DC PNP type:
Common = 0V
Logic "0": Input < 5 V DC
Logic "0": Input > 10 V DC
NPN type:
Common = 24 V
Logic "0": Input > 19 V DC
Logic "0": Input < 14 V DC
Standardised input signal
0-10V DC
Output level
0 V or 2 V DC
Output signal level
0/4 - 20 mA
Danfoss A/S © Rev. 06/2014 All rights reserved.
Tolerance
± 28 V continuous
± 37 V in minimum 10
sec.
Tolerance Resolution
± 20 V continuously 10 bits
Tolerance
± 4 V
Tolerance
± 0.1 mA
Max. Input impedance
Approx. 5 kΩ
Max. Input impedance
Approx. 5 KΩ
Max. impedance
≥ 600Ω
Max. impedance
< 500Ω
