Selection
NOTICE
Note the values available within the different standard
groups of resistors:
E12: Closest standard value is 470 Ω, creating an input of
449.9 Ω and 8.997 V.
E24: Closest standard value is 510 Ω, creating an input of
486.4 Ω and 9.728 V.
E48: Closest standard value is 511 Ω, creating an input of
487.3 Ω and 9.746 V.
E96: Closest standard value is 523 Ω, creating an input of
498.2 Ω and 9.964 V.
3 x Analog inputs
Operating range
Used as
-50°C to +150°C
temperature
sensor input
Used as
0 - 10 V DC
voltage input
Table 3.8 Analog Inputs
When used for voltage, analog inputs are scalable by
parameters for each input.
When used for temperature sensor, analog inputs scaling is
preset to necessary signal level for specified temperature
span.
When analog inputs are used for temperature sensors, it is
possible to read out feedback value in both °C and °F.
When operating with temperature sensors, maximum cable
length to connect sensors is 80 m non-screened/non-
twisted wires.
Analog outputs - terminal X42/7-12
Parameter group for read out and write: 18-3*. For more
information, consult the Programming Guide.
Parameter groups for set-up: 26-4* Analog Out X42/7, 26-5*
Analog Out X42/9 and 26-6* Analog Out X42/11. For more
information, consult the Programming Guide.
3 x Analog
Output
Resolution Linearity
outputs
signal level
Volt
0-10V DC
11 bits
Table 3.9 Analog Outputs
Analog outputs are scalable by parameters for each
output.
The function assigned is selectable via a parameter and
have same options as for analog outputs on control card.
MG20Z202
Design Guide
Resolution
Accuracy
11 bits
-50 °C
±1 °K
+150 °C
±2 °K
0.2% of full
10 bits
scale at cal.
temperature
Max load
1% of full
1 mA
scale
Danfoss A/S © Rev. 06/2014 All rights reserved.
Analog inputs - terminal X42/1-6
Parameter group for read out: 18-3* Analog Readouts. For
more information, consult the Programming Guide.
Parameter groups for set-up: 26-0* Analog I/O Mode, 26-1*
Analog Input X42/1, 26-2* Analog Input X42/3 and 26-3*
Analog Input X42/5. For more information, consult the
Programming Guide.
Sampling
Max load
3 Hz
+/- 20 V
2.4 Hz
continuously
For a more detailed description of parameters, refer to the
Programming Guide.
Parameter group for read out and write: 18-3*. For more
information, consult the Programming Guide.
Parameter groups for set-up: 26-4* Analog Out X42/7, 26-5*
Analog Out X42/9 and 26-6* Analog Out X42/11. For more
information, consult the Programming Guide.
3 x Analog
Output
Resolution Linearity
outputs
signal level
Volt
0-10V DC
11 bits
Table 3.10 Analog Outputs
Analog outputs are scalable by parameters for each
output.
The function assigned is selectable via a parameter and
have same options as for analog outputs on control card.
For a more detailed description of parameters, refer to the
Programming Guide.
Real-time clock (RTC) with back-up
The data format of RTC includes year, month, date, hour,
minutes, and weekday.
Accuracy of clock is better than ± 20 ppm at 25 °C.
The built-in lithium back-up battery lasts on average for
minimum 10 years, when the frequency converter is
Impedance
-
-
Approximately
5 kΩ
Max load
1% of full
1 mA
scale
