How to Install
Terminal Locations - D3h/D4h
Take the following position of the terminals into consideration when designing the cable access.
5
5
Illustration 5.64 Position of Ground Terminals IP20 (Chassis), D3h/D4h
1
Ground Terminals
Table 5.12 Legend to Illustration 5.63 and Illustration 5.64
106
Design Guide
1
Danfoss A/S © Rev. 06/2014 All rights reserved.
MG20Z202
