Danfoss VLT AQUA Drive FC 202 Design Manual page 69

How to Order
Code number Code number
AHF005 IP00/ AHF010 IP00/
IP20 IP20
2x130B5274 2x130B5242
2x130B5259 2x130B5225
2x130B5275 2x130B5243
2x130B5260 2x130B5226
3x130B5274 2x130B5244
3x130B5259 2x130B5227
3x130B5274 2x130B5244
3x130B5259 2x130B5227
3x130B5275 3x130B5243
3x130B5260 3x139B5226
4x130B5274 3x130B5244
4x130B5259 3x130B5227
4x130B5275 3x130B5244
4x130B5260 3x130B5227
4x130B5244
4x130B5227
Table 4.13 Advanced Harmonic Filters, 600 V, 60 Hz
Code number Code number
AHF005 IP00/ AHF010 IP00/
IP20 IP20
130B5024 130B5325
130B5169 130B5287
130B5025 130B5326
130B5170 130B5288
130B5026 130B5327
130B5172 130B5289
130B5028 130B5328
130B5195 130B5290
130B5029 130B5329
130B5196 130B5291
130B5042 130B5330
130B5197 130B5292
130B5066 130B5331
130B5198 130B5293
130B5076 130B5332
130B5199 130B5294
2x130B5042 130B5333
2x130B5197 130B5295
2x130B5042 130B5334
130B5042 130B5330
+130B5066 +130B5331
130B5197 130B5292
+130B5198 +130B5293
Table 4.14 Advanced Harmonic Filters, 500-690 V, 50 Hz
MG20Z202
Design Guide
Filter
current
Typical VLT model and
rating motor current ratings
50 Hz
[A] [HP] [kW]
480 500 P500
592 600 P560
732 650 P630
732 750 P710
888 950 P800
960 1050 P900
1098 1150 P1M0
1580 1350 P1M2
Filter
current VLT model and current ratings
rating
Typical
50 Hz motor 500-550 V
size
[A] [kW] [kW] [A]
77 45 N55K 71
87 55 N75K 89
109 75 N90K 110
128 90 N110 130
155 110 N132 158
197 132 N160 198
240 160 N200 245
296 200 N250 299
366 250 N315 355
395 315 N355 381
437 355 N400 413
Danfoss A/S © Rev. 06/2014 All rights reserved.
Losses
AHF005 AHF010
[A] [W] [W]
482 3020 2350
549 3704 2576
613 4530 3084
711 4530 3084
828 5556 3864
920 6040 4626
1032 7408 4626
1227 6168
Losses
Typical
motor 551-690 V AHF005 AHF010
size
[kW] [kW] [A] [W]
75 N75K 76 841
962
90 N90K 104 1080
110 N110 126 1194
132 N132 150 1288
160 N160 186 1406
200 N200 234 1510 1175
250 N250 280 1852 1288
315 N315 333 2812 1542
400 2812 1852
500 N400 395 2916 2127
Acoustic
Frame size
noise
[dBa] AHF005 AHF010
Acoustic
Frame size
noise
[W] [dBa] AHF005 AHF010
488 <72 X6 X6
692 <72 X6 X6
743 <72 X6 X6
864 <72 X6 X6
905 <72 X7 X7
952 <72 X7 X7
<75 X8 X7
<75 X8 X8
X8
X8
4 4
67
