How to Order
Description
Enclosure
4 4
RFI filter
Brake
Display
Coating PCB
Mains option
60
Design Guide
Pos Possible choice
13- E21: IP 21/NEMA Type 1
15 E54: IP 54/NEMA Type 12
L2X: IP21/NEMA 1 with cabinet light & IEC 230 V power outlet
L5X: IP54/NEMA 12 with cabinet light & IEC 230 V power outlet
L2A: IP21/NEMA 1 with cabinet light & NAM 115 V power outlet
L5A: IP54/NEMA 12 with cabinet light & NAM 115 V power outlet
H21: IP21 with space heater and thermostat
H54: IP54 with space heater and thermostat
R2X: IP21/NEMA1 with space heater, thermostat, light & IEC 230 V outlet
R5X: IP54/NEMA12 with space heater, thermostat, light & IEC 230 V outlet
R2A: IP21/NEMA1 with space heater, thermostat, light, & NAM 115 V outlet
R5A: IP54/NEMA12 with space heater, thermostat, light, & NAM 115 V outlet
16- B2: 12-pulse with class A2 RFI
17 BE: 12-pulse with RCD/A2 RFI
BH: 12-pulse with IRM/A1 RFI
BG: 12-pulse with IRM/A2 RFI
B4: 12-pulse with class A1 RFI
BF: 12-pulse with RCD/A1 RFI
BH: 12-pulse with IRM/A1 RFI
H2: RFI filter, class A2 (standard)
H4: RFI filter, class A1
HE: RCD with Class A2 RFI filter
HF: RCD with class A1 RFI filter
HG: IRM with Class A2 RFI filter
HH: IRM with class A1 RFI filter
HJ: NAMUR terminals and class A2 RFI filter
HK: NAMUR terminals with class A1 RFI filter
HL: RCD with NAMUR terminals and class A2 RFI filter
HM: RCD with NAMUR terminals and class A1 RFI filter
HN: IRM with NAMUR terminals and class A2 RFI filter
HP: IRM with NAMUR terminals and class A1 RFI filter
18 B: Brake IGBT-mounted
C: Safe stop with Pilz safety relay
D: Safe stop with Pilz safety relay and brake IGBT
E: Safe stop with Pilz safety relay and regeneration terminals
X: No brake IGBT
R: Regeneration terminals
M: IEC Emergency stop push-button (with Pilz safety relay)
N: IEC Emergency stop push button with brake IGBT and brake terminals
P: IEC Emergency stop push button with regeneration terminals
19 G: Graphical Local Control Panel LCP
20 C: Coated PCB
21 X: No mains option
7: Fuse
2)
3 : Mains disconnect and fuse
2)
5 : Mains disconnect, fuse, and load sharing
A: Fuse and Load sharing
D: Load sharing
E: Mains disconnect, contactor & fuses
F: Mains circuit breaker, contactor & fuses
G: Mains disconnect, contactor, loadsharing terminals & fuses
H: Mains circuit breaker, contactor, loadsharing terminals & fuses
J: Mains circuit breaker & fuses
K: Mains circuit breaker, loadsharing terminals & fuses
