5.5 Input Options

5.5.1 Mains Disconnects

Frame size
380-500 V
D5h/D6h
D7h/D8h
E1/E2
E1/E2
F3
5 5
F3
F4
525-690 V
D5h/D6h
D5h/D6h
F3
F3
F4
Table 5.17 Mains Disconnects, D, E and F- frame Frequency Converters
Frame size
380-500 V
F9
F9
F9
F9
F11
F11
F11
F11
F13
F13
525-690 V
F9
F9
F9
F9
F11
F11
F11
F13
F13
F13
Table 5.18 Mains Disconnects, 12-Pulse Frequency Converters
130
Design Guide
Power
N110-N160
N200-N400
P250
P315-P400
P450
P500-P630
P710-P800
N75K-N160
N200-N400
P630-P710
P800
P900-P1M2
Power
P250
P315
P355
P400
P450
P500
P560
P630
P710
P800
P355
P400
P500
P560
P630
P710
P800
P900
P1M0
P1M2
Danfoss A/S © Rev. 06/2014 All rights reserved.
Type
ABB OT400U03
ABB OT600U03
ABB OETL-NF600A
ABB OETL-NF800A
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NRKF36000S20AAYP
Merlin Gerin NRKF36000S20AAYP
ABB OT400U03
ABB OT600U03
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NRKF36000S20AAYP
Merlin Gerin NRKF36000S20AAYP
Type
ABB OETL-NF600A
ABB OETL-NF600A
ABB OETL-NF600A
ABB OETL-NF600A
ABB OETL-NF800A
ABB OETL-NF800A
ABB OETL-NF800A
ABB OT800U21
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NPJF36000S12AAYP
ABB OT400U12-121
ABB OT400U12-121
ABB OT400U12-121
ABB OT400U12-121
ABB OETL-NF600A
ABB OETL-NF600A
ABB OT800U21
ABB OT800U21
Merlin Gerin NPJF36000S12AAYP
Merlin Gerin NPJF36000S12AAYP
MG20Z202
