No. Description
37 Phase imbalance
38 Internal fault
39 Heatsink sensor
40 Overload of digital output terminal 27
41 Overload of digital output terminal 29
42 Overload of digital output on X30/6
42 Overload of digital output on X30/7
46 Pwr. card supply
47 24 V supply low
48 1.8 V supply low
49 Speed limit
50 AMA calibration failed
51 AMA check U
52 AMA low I
53 AMA motor too big
54 AMA motor too small
55 AMA parameter out of range
56 AMA interrupted by user
57 AMA timeout
8 8
58 AMA internal fault
59 Current limit
60 External interlock
62 Output frequency at maximum limit
64 Voltage limit
65 Control board over-temperature
66 Heat sink temperature low
67 Option configuration has changed
68 Safe torque off
69 Pwr. card temp (E- and F-frame only)
70 Illegal FC configuration
71 PTC 1 safe torque off
72 Dangerous failure
73 Safe torque off auto restart
76 Power unit setup
79 Illegal PS config
80 Drive initialized to default value
91 Analogue input 54 wrong settings
92 NoFlow
93 Dry pump
94 End of curve
95 Broken belt
96 Start delayed
97 Stop delayed
98 Clock fault
104 Mixing fan fault
201 Fire M was active
202 Fire M limits exceeded
203 Missing motor
204 Locked rotor
243 Brake IGBT
244 Heatsink temp
245 Heatsink sensor
190
and I
nom nom
nom
