3.4.10 Enclosure Size F USB Extension Kit

A USB extension cable can be installed into the door of F-
frame frequency converters.
Ordering information:
•
176F1784

3.4.11 Installation of Input Plate Options

This section describes the field installation of input option kits available for frequency converters in all E enclosures.
Do not attempt to remove RFI filters from input plates. Damage may occur to RFI filters if they are removed from the input
plate.
NOTICE
2 different types of RFI filters are available, depending on the input plate combination and the RFI filters
interchangeable. Field installable kits are, in certain cases, the same for all voltages.
380–480 V
380-500 V
E1 FC 102/FC 202: 315 kW
FC 302: 250 kW
FC 102/FC 202: 355–450
kW
FC 302: 315–400 kW
Table 3.10 Fuses, Enclosure Size E1 380-500 V
525–690 V
E1 FC 102/FC 202: 450–
500 kW
FC 302: 355–400 kW
FC 102/FC 202: 560–
630 kW
FC 302: 500–560 kW
Table 3.11 Fuses, Enclosure Size E1 525-690 V
NOTICE
For further information, see the Instruction Installation of Field Installable Kits for VLT Drives.
MG11F502
Operating Instructions
NOTICE
For further information, see the Instruction Sheet,
177R0091.
Fuses Disconnect fuses
176F0253 176F0255
176F0254 176F0256
Fuses Disconnect fuses
176F0253 176F0255
176F0254 176F0258
