4 How to Install

4.4 Field Installation of Options

4.4.1 Installation of Input Plate Options

This section is for the field installation of input option kits available for frequency converters in all D and E frames.
Do not attempt to remove RFI filters from input plates. Damage may occur to RFI filters if they are removed from the input plate.
NB!
Where RFI filters are available, there are two different type of RFI filters depending on the input plate combination and the RFI filters
4
interchangeable. Field installable kits in certain cases are the same for all voltages.
380 - 480 V
380 - 500 V
D11
E7 FC 102/ 202: 315 kW
FC 302: 250 kW
FC 102/ 202: 355-450 kW
FC 302: 315-400 kW
NB!
For further information, please see the Instruction Sheet,

4.4.2 Installation of Mains Shield for Frequency Converters

The mains shield is for installation with D and E frames and satisfy BG-4 requirements.
Ordering numbers:
D frames: 176F0799
E frames: 176F1851
NB!
For further information, please see the Instruction Sheet,

4.5 Frame size F Panel Options

Space Heaters and Thermostat
Mounted on the cabinet interior of frame size F frequency converters, space heaters controlled via automatic thermostat help control humidity inside the
enclosure, extending the lifetime of drive components in damp environments. The thermostat default settings turn on the heaters at 10° C (50° F) and
turn them off at 15.6° C (60° F).
Cabinet Light with Power Outlet
A light mounted on the cabinet interior of frame size F frequency converters increase visibility during servicing and maintenance. The housing the light
includes a power outlet for temporarily powering tools or other devices, available in two voltages:
• 230V, 50Hz, 2.5A, CE/ENEC
• 120V, 60Hz, 5A, UL/cUL
Transformer Tap Setup
40
Fuses Disconnect Fuses
176F8443 176F8441
176F0253 176F0255
176F0254 176F0256
175R5795
175R5923
®
MG.20.T1.02 - VLT is a registered Danfoss trademark
VLT AQUA Low Harmonic Drive Operating In-
RFI RFI Fuses
176F8445 176F8449
176F0257 176F0258
176F0257 176F0259
structions
RFI Disconnect
Fuses
176F8447
176F0260
176F0262
