CDM-710/L Broadcast Satellite Modem
Front Panel Operation
(CONFIG:) Intfc2 Gigabit Ethernet:  Egress  IP  DestPort
To enter a valid UDP Destination Port Address for the egress packet stream, first
use the ◄ ► arrow keys to select the digit, and then use the ▲▼ arrow keys to
change that digit. Press ENTER.
Media packets will be addressed to this UDP port; FEC packets (if FEC
generation is enabled) will be addressed to (UDP destination port +2).
(CONFIG:) Intfc2 Gigabit Ethernet:  Man
To enter the Management IP Address/subnet mask for Gigabit Ethernet Interface
Management Channel, first use the ◄ ► arrow keys to select the digit, and then
use the ▲▼ arrow keys to change that digit. Press ENTER.
(CONFIG:) Intfc2 Gigabit Ethernet:  Stats
Use the ◄ ► arrow keys to select View or Clear. Press ENTER.
(CONFIG:) Intfc2 Gigabit Ethernet:  Stats  View
The nested screens present statistics on a per-category basis. Use the ▲▼
arrow keys to page through the available statistics reports. Press ENTER or
CLEAR when done.
Intfc2 Egress Multicast:
01024
Intfc2 Management IP
192.168.001.008/24
Intfc2 Statistics
View Clear
FPGA Packets Dropped
00000000000000000000
7–44
MN/CDM710.IOM
()
()
Revision 12
