Comtech EF Data CDM-710 Installation And Operation Manual page 237

CDM-710/L Broadcast Satellite Modem
Serial Interface Operation
Controller-to-Target
Instruction Code & Qualifier
Parameter
Type
Command Query
Auto Switch ASW= ASW?
Mode
Rx BER N/A BER?
Clear All CAE= N/A
Stored Events
Circuit ID CID= CID?
String
Configuration CLD= N/A
Load
Configuration CST= N/A
Save
Number of
Arguments for
Command or
(Note that all arguments are ASCII numeric codes from 48 and 57)
Response to
Query
1 byte Command or Query.
Unit returns the redundancy auto/manual mode of the unit in the form x
where:
0=Manual
1=Automatic
COMMAND EXAMPLE: <0001/ASW=0{CR} (sets Manual switching mode)
7 bytes Query only.
Returns the value of the estimated BER in the form a.bEscc, (representing ab
-c
x 10 ), where:
a.b=BER value
E=exponent indicator
s= sign (+/-)
cc=exponent value.
NOTE: Unit returns 0.0E+00 if the demodulator is unlocked.
EXAMPLE: <0001/BER?{CR}
>0001/BER=4.8E-03{CR}{LF} (returns BER of 4.8 x 10
None Command only.
THIS COMMAND TAKES NO ARGUMENTS.
Forces the unit to clear the stored events log.
EXAMPLE: <0001/CAE={CR}
24 bytes Command or Query.
Sets or returns the user-defined Circuit ID string, which is a fixed length of 24
characters. Valid characters include: Space ( ) * + – , ./ 0 9 and A thru Z
NOTE: Trailing spaces are removed upon entry.
COMMAND EXAMPLE: <0001/CID=ComtechCDM-710L{CR}
1 byte Command only.
Retrieves previously stored configuration from the specified location in the
form x where:
x=0 to 9
EXAMPLE: <0001/CLD=4{CR} (retrieves configuration from location 4)
1 byte Command only.
Stores the current configuration in the specified location in the form x where:
x=0 to 9
EXAMPLE: <0001/CST=4{CR} (stores the current configuration in location 4)
9–29
Description of Arguments
-3
)
MN/CDM710.IOM
Revision 12
Target-to-Controller
(See Description of Arguments)
Response to Response to
Command Query
ASW= ASW=x
ASW?
ASW*
ASW#
BER? BER=a.bEscc
BER*
BER#
CAE= N/A
CAE?
CAE*
CAE#
CID= CID=xxxxxxxxxxx
CID? xxxxxxxxxxxxx
CID*
CID#
CLD= N/A
CLD?
CLD*
CLD#
CST= N/A
CST?
CST*
CST#
