CDM-710/L Broadcast Satellite Modem
Ethernet Interface Operation
8.2.1.8.3

ASI Private MIB

The CDM-710 ASI MIB holds all unit parameters associated with the ASI
interface board.
8.2.1.8.4

Redundancy-Switch Private MIB

The CDM-710 Modem MIB holds all unit parameters associated with 1:1
Redundancy operations.
8.2.1.8.5

Gigabit Ethernet MIB

The CDM-710 Modem MIB holds all unit parameters associated with the
Gigabit Ethernet Interface.

8.2.1.9 HSSI MIB

SNMP for the HSSI interface is not supported at this time.

8.2.2 SNMP Community Strings

CAUTION
In SNMP v1/v2c, the SNMP Community String is sent unencrypted in the
SNMP packets. Caution must be taken by the network administrator to
ensure that SNMP packets travel only over a secure and private network
if security is a concern.
For correct SNMP operation, the unit MIB files must be used with the
associated version of the unit M&C. See the CDM-710/L FW Release
Notes for information on the required FW/SW compatibility.
The CDM-710/L uses Community Strings as a password scheme that provides
authentication before gaining access to the router agent's MIBs. They are used
to authenticate users and determine access privileges to the SNMP agent. The
CDM-710/L defines three Community Strings for SNMP access:
• Read Community
• Write Community
• Trap Community
default = public
default = private
default = comtech
