CDM-710/L Broadcast Satellite Modem
Appendix D
D.2.1 CDI-70 'GBEI | J1' RJ-45 Connector Pinout
D.3 CDI-70 Specifications
D.3.1

Physical and Environmental Specifications

Physical Dimensions
3.95 W x 7.022 D x 1.5 H inches (10.03 W x 17.83 D x 3.81H cm) PCB / Plug-in
Module.
Environmental
• Humidity: 95% maximum, non-condensing.
• Temperature:
o 0° to 50°C (32° to 122°F) Operating Temperature.
o -40° to +70°C (-40° to 158°F) Storage Temperature.
• Mechanical: Compatible with CDM-710 and CDM-710L rear panel
Interface Slot 2.
• Agency Approval: CE in conjunction with the modem.
D.3.2

General Specifications

Modules per Modem
The interface operates in Interface Slot 2 only.
Pin # Description
1 BI_DA+
2 BI_DA-
3 BI_DB+
4 BI_DC+
5 BI_DC-
6 BI_DB-
7 BI_DD+
8 BI_DD-
D–4
Direction
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
bidirectional
MN/CDM710.IOM
Revision 12
