CDM-710/L Broadcast Satellite Modem
Ethernet Interface Operation
Trap Version – Use the drop-down list to select SNMPv1 or SNMP v2c.
Click [Submit Admin] to save.
8.5.3 Config Mdm (Configure Modem) Pages
Use these pages to configure all operating parameters for the CDM-710/L.
Click Interface, Modem, or Modem Utilities to continue.

8.5.3.1 Configuration | Interface

See Chapter 2. SPECIFICATIONS the listing of applicable data
interfaces and installable combinations.
Use this page to configure data interfaces as they may be installed in modem
Expansion Slot 1 (Intfc1) and Expansion Slot 2 (Intfc2).
This page appearance depends on the presence of installed interfaces. For either
slot, the unit automatically detects the interface type and adjusts the
appearance of the Expansion Slot sections to suit.
In Figure 8-11, a CDI-60 HSSI Interface Module is present in Expansion Slot 1, and
a CDI-70 Gigabit Ethernet Interface (GBEI) Module is present in Expansion Slot 2.
Figure 8-12 shows how the page appears when no interface module is present.
In this example, a CDI-40 ASI Interface Module is present in Expansion Slot 1,
while Expansion Slot 2 is empty. The message "Interface Not Installed." displays
in place of a functional configuration window.
Define the desired interface operating parameters. Click [Submit Changes] to
save.
