Specifications
8.4 General Technical Data - Filter
Frame size
Voltage [V]
Current, RMS [A]
Response time [ms]
Settling time - reactive current control [ms]
Settling time - harmonic current control (filtering) [ms]
Overshoot - reactive current control [%]
Overshoot - harmonic current control [%]
Table 8.4 Power Ranges (LHD with AF)
8.4.1 Power Rating
Grid conditions
Supply voltage
Mains voltage low/mains drop-out:
During low mains voltage or a mains drop-out, the filter continues until the intermediate circuit voltage drops below the
minimum stop level, which corresponds to 15% below the filter lowest rated supply voltage. Full compensation cannot be
8
8
expected at mains voltage lower than 10% below the filter lowest rated supply voltage. If mains voltage exceed the filter highest
rated voltage, the filter continues to work but harmonic mitigation performance is reduced. The filter does not cut out until main
voltages exceed 580 V.
Supply frequency
Max. imbalance temporary between mains phases
where mitigation performance is kept high.
Max THDv pre-distortion
Harmonic mitigation performance
THiD
Individual harmonic mitigation ability:
2nd
4th
5th
7th
8th
10th
11th
13th
14th
16th
17th
19th
20th
22nd
23rd
25th
Total current of harmonics
The filter is performance tested to the 40th order
Reactive current compensation
Cos phi
Reactive current, % of filter current rating
86
Operating Instructions
380–480
Filter mitigates at higher mains imbalance but harmonic mitigation
Danfoss A/S © Rev. 2014-01-22 All rights reserved.
D13
E9
380–480
120
210
<0.5
<40
<20
<20
<10
10% with kept mitigation performance
Reduced performance for higher pre-distortion levels
Depending on filter vs. distortion ratio.
Current maximum RMS [% of rated RMS current]
Controllable 1.0 to 0.5 lagging
F18
380–480
330
380–480 V
50/60 Hz ±5%
3.0% of rated supply voltage
performance is reduced
Best performance <4%
10%
10%
70%
50%
10%
5%
32%
28%
4%
4%
20%
18%
3%
3%
16%
14%
90%
100%
MG21B202
