Field Name Range
Switch DVR from
Enable /
LOC to SYS if
Disable
MSU CH
check box
Emergency

Tone Setup Menu

The tones setup screen allows programming of custom tones / tone sequences, which
are sent by the DVR to the Analog PSUs during Analog Mode of operation only.
If no custom tones are programmed, the DVR will send the default sets of tones.
NOTE
The Tones sent by the DVR in Analog Mode are heard by all Analog PSUs, which are
tuned to the same DVR channel and are within the DVR RF coverage area.

Morse Code Menu

The Morse code option needs to be programmed only when a DVRS is to be used as a
Fixed repeater and the FCC Rules require transmission of Repeater ID via Morse Code.
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Description
When the DVR is in the LOC
mode and the user presses the
Emergency button on the MSU
CH the DVR will switch from LOC
to SYS mode when this option is
enabled (box is checked). If the
option is not enabled, the DVR
stays in LOC mode
Emergency is declared on the
MSU.
TM
5000 (O3 or O5) or XTL
8M083X01 Rev. 16
Notes
after
TM
2500 (M5)
6881013Y39
Page 37 of 79
