Heart Beat
HUB
Inbound Call
Local Mode
Local PSU
M5
Mobexcom II
Mode
MPE
MSU
Outbound Call
O5 / O3
PSU
PTT
RF
RSSI
April 2014
DVRS Installation & Programming Guide – PART I
P25 Message periodically sent by Primary DVR to other DVRs
during Primary/Secondary processing.
Hang Up Box – if this feature is enabled in the DVR and the
microphone is off hook, any audio received form the Local
PSUs, regardless of the PL/DPL will be heard on the MSU
speaker. Applicable to Digital Mode only.
A Call transmitted by Local PSU and received by the DVR.
DVR Mode which provides extended portable-to-portable voice
and data range by repeating Local PSU (optionally MSU)
communications without keying up the Mobile radio interfaced
to the DVR.
PSU in DVR Mode.
For example:
In Digital DVR Mode – Affiliated PSU through the DVR.
In Analog Mode – PSU with the current Analog DVR channel
selected.
TM
XTL 2500 Control Head using CAN bus.
Analog Vehicular Repeater, NOT compatible with XTL
radios using CAN bus Control Heads such as the O5 / O3.
Mobexcom II can be interfaced to XTL
Control Heads, Astro Spectra or MCS2000 Mobile Radios.
MSU / PSU - A programmed combination of operating
parameters.
DVR – OFF, SYSTEM or LOCAL (see DVR Mode)
Maximum Permissible Exposure.
Mobile Subscriber Unit - XTL
System Call received by the MSU.
TM
XTL 5000 Odyssey 5 / 3 Control Head using CAN bus.
Portable Subscriber Unit.
Push to talk. The PTT engages the transmitter (of the Portable
or Mobile radio and / or DVR) when pressed.
Radio Frequency. Part of the general frequency spectrum
10kHz - 10,000,000 MHz.
Received Signal Strength Indicator.
8M083X01 Rev. 16
TM
5000 using W-series
TM TM
5000 or XTL 2500
6881013Y39
TM
5000
