Foreword
This manual provides Installation and Programming guidelines for all models of the
Futurecom Mobexcom P25 Digital Vehicular Repeater (DVR).
The P25 Digital Vehicular Repeater (DVR) is designed to be seamlessly interfaced to a
TM TM
Remote Mount XTL 2500 or XTL 5000 Digital Mobile Subscriber Unit (MSU) with M5,
O3 or O5 Control Head.
TM
When the DVR is interfaced to a Remote Mount XTL 5000, the complete equipment
package is referred to as Digital Vehicular Repeater System (DVRS).
The DVR may also be used as a stand alone (Tactical) repeater. The operation of the
Tactical DVR is described in publication 8A083X21. The Installation & Programming
Guidelines referring to the Tactical DVR Model are described in document 8M083X02.
TM
The DVR can not be interfaced to XTL 5000 radios which are using the W-series
control heads.
For W-series Control Head compatible equipment, please refer to the Mobexcom II
Analog VR Documentation.
For details on the DVRS Operation, please refer to the DVRS User's Guide 8A083X20.
TM
For details on the XTL 5000 Mobile Radio operation, please refer to the applicable
Manuals available from Motorola.
The DVRS Operation described in this Document requires the following Firmware:
TM TM
XTL 2500 / XTL 5000 - firmware release: Host R20.00.05
TM TM TM
XTS 1500 /XTS 2500 / XTS 5000 - firmware release R17.01.01
TM TM TM
APX 4000 / APX 6000 / APX 7000 – firmware release R07.00.05 or later
O3/O5/M5 Control Head - firmware releases R16.00.0 0
DVR must be loaded with firmware release: Application 4C083X01 R03.41 or later
Tweaker Programming software – Version 3.45 or later
