DVRS Programming Guidelines

Programming Steps Overview

The DVRS operation depends on the following:
DVR Firmware and Programming settings
TM
MSU (XTL 2500 / XTL
PSU Firmware and Programmed Personality
P25 Trunking System Infrastructure
To enable a given DVR Feature, all of the above components must be adequately setup
and matched to support it.
IMPORTANT
Changes to any of the personality templates may require corresponding
adjustments to the personality templates of the rest of the system components.
To ensure consistent programming of all components, the following programming
sequence is recommended:
Step
1 Create the MSU template with enabled DVR
Operation and save it. Ensure the desired MSU
Talk Groups / Modes are set to 'DVRS Enabled'
and there are no frequency spacing issues (In-
Band models only).
Export ALL in a .csv file and save it.
2
Create a .dpd file and program the licensed DVR
3
Channels. Ensure the DVR frequencies are
within the ordered filtering specification.
Import the saved .csv file.
4
Program the Mobile Channel attributes as
5
required.
6 Program the desired Analog / Digital Mode
Features in the DVR.
7 Save the .dpd template.
8 Create the PSU template. Ensure DVR
Operation is Enabled and the settings match
those programmed in the DVRS.
9 Save the PSU codeplug.
10 Ensure all personality templates are matched in terms of frequencies, PL/DPL,
TX/RX NIDs, enabled and disabled features etc. and confirm (through testing) the
DVRS operation before field deployment.
Table 1 Recommended Programming Sequence
IMPORTANT
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
TM
5000) Firmware and Programmed Personality
Action
TM
5000 (O3 or O5) or XTL
8M083X01 Rev. 16
Software Program Used
Mobile CPS (Motorola)
Mobile CPS (Motorola)
Tweaker (Futurecom)
Tweaker (Futurecom)
Tweaker (Futurecom)
Tweaker (Futurecom)
Tweaker (Futurecom)
Portable Radio CPS (Motorola)
Portable Radio CPS (Motorola)
TM
2500 (M5)
6881013Y39
Page 11 of 79
