Local PSU
Call Alert (Page)
to:
SECONDARY
DVRS A
PSU on TG1
MSU CONV1
Table 3 Typical Remote Steering Scenarios
The following Table illustrates the programming requirements pertaining to all templates
involved (DVR, PSUs):
DVR Programming –
Repeater Channel Setup:
CH # RX TX
NID NID
1 F7E 4
*Note
Table 4 Programming Example - Remote Steering
NOTE:
F7E Enables the DVR / PSU to receive on any NID and TG ID.
The F7E setting ensures the DVR will receive when the PSU transmits different TX NIDs
(4, 5, 6 in the above example).
When a PSU User selects TG2 and sends a Call Alert / Page to the DVR (Using the
unique DVR ID Number), the PSU will transmit with TX NID 5. The DVR will detect Steer
NID 5 and switch the MSU to TG2.
The DVR will be repeating the Call with TX NID 4, which is received by the PSU on any
of the steerable TGs.
All of the above settings refer to DVR CH1 i.e. the PSU remotely steers TGs on the
same DVR channel. DVR channel steering is not recommended.

Dispatcher Control

Dispatcher can send a Call Alert (Page) to a specific MSU, which in turn causes DVR
mode change in the following order: OFF-SYS-LOC-OFF.
It is recommended that remote mode change is disabled in the MSU and enabled in the
DVR. If remote mode change is enabled in the MSU then the Call Alert Page feature
must be available to the Dispatcher only. The rest of the system subscriber equipment
must not have the Call Alert (Page) feature enabled since paging a specific MSU
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
DVRS A
Steering
BEFORE AFTER
OFF OR SYSTEM
LOCAL
PRIMARY
DVR CH 1 DVR CH 1
MSU TG 1
DVR Programming –
Mobile Radio Channel Setup:
TG /CH Steer
Name NID
TG1
TG2
CONV1
TM
5000 (O3 or O5) or XTL
BEFORE
LOCAL OR
SYSTEM
PRIMARY
DVR CH 1
MSU TG 1
PSU
Template - DVR CH 1:
VRch
4 1
5 1
6 1
TM
2500 (M5)
8M083X01 Rev. 16
6881013Y39
DVRS B
Steering
AFTER
LOCAL OR SYSTEM
SECONDARY
DVR CH 1
MSU TG 1
Programming
RX TX TG /
NID NID CH
4 4 TG1
4 5 TG2
4 6 CONV1
