No part of this document, or any software included with it, may be reproduced and distributed without the prior written permission of the copyright holder. Futurecom Systems Group Inc. reserves the right to make changes or improvements to the equipment, software or specification described in this document at any time and without prior notice. These changes will be incorporated in the new releases of this document.
Using the Programming Software On-Line..............13 SETTING UP THE OCR MAXIMUM GAIN..............14 Downlink Maximum Gain Setting: ................14 Uplink Maximum Gain Setting: ..................14 OCR FRONT PANEL INDICATORS.................. 16 OCR Specifications ....................... 17 8A535X03 Rev. Preliminary-00 Page 3 of 17...
ABOUT THIS DOCUMENT This document describes the operation of the Futurecom On-Channel Repeater (OCR). It provides setup guidelines and outlines the programming options, which are accessible through the programming software (6A074X01). Notes, Attentions, Important Throughout this manual, you will see Notes, Attentions and Important.
ATTENTION! Changes or Modifications not expressly approved by Futurecom Systems Group Inc. could void the user’s authority to operate the equipment. GENERAL SAFETY INFORMATION The following information may or may not be applicable to your product.
RADIO OPERATOR Futurecom requires the OCR operator to ensure FCC Requirements for Radio Frequency Exposure are met. The OCR output power has to be set such that the maximum Effective Radiated Power (ERP) does not exceed 5W at the antenna. The minimum distance between all possible personnel and the antenna at 5W ERP must be at least 25.4cm (10.0”).
Page 7
For General Population/bystanders: r = (ERP/4ПS) = (5000/4П(931.0125/1500)) = 25.32cm. The MPE safe distance is therefore at least 25.4cm (10.0”). ATTENTION! The MOBEXCOM OCR must be restricted to occupational use only to satisfy FCC RF Exposure requirements. 8A535X03 Rev. Preliminary-00 Page 7 of 17...
Page 8
Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. RF Exposure Label 8A535X03 Rev. Preliminary-00 Page 8 of 17...
The chassis of the OCR is made from aluminium. The rugged construction minimizes microphonics and internal feedback. The OCR installation is performed by simply plugging it into a double Eurocard format 19” EIA rack mount card cage. 8A535X03 Rev. Preliminary-00 Page 9 of 17...
The front panel RESET and TX DISABLE inputs are monitored and can be accesses via two front panel holes with a round tool 2.5mm (0.1”) diameter. The front panel indicators (TX DIS, DC ON, TX ON, RX ON, PWR and VSWR) are also controlled by the Controller Board. 8A535X03 Rev. Preliminary-00 Page 10 of 17...
The OCR is easily installed by plugging it into the Eurocard format card cage which can accommodate up to five OCRs. The DC supply wiring must be connected to nominal 27.6VDC. For more information on multi channel options call the Futurecom sales department to obtain a quotation. Master Shelf...
The programming software can be run either from Windows or MS DOS. Copy the files from the Futurecom supplied disk into a separate directory / folder on your PC. Create a shortcut (Windows) or use the supplied batch file by typing in the path to the .exe file location on the specific PC. Run the programming software by clicking on the shortcut or typing the batch file name.
For successful On-Line operation the OCR needs to be properly connected prior to commencing the programming / system setup: 1. The OCR must be plugged into the Futurecom subrack and supplied with proper DC power supply. 2. The RF IN and RF OUT ports need to be connected to the corresponding multicoupling ports or to adequate power rating 50 Ohm loads (or to the test equipment).
Set the power output to the calculated level required to reach the Donor site (allow for at least 6 dB margin). Key up the OCR by setting PTT to ON. Read the “own” ?RSSI level from the Maintenance screen 8A535X03 Rev. Preliminary-00 Page 14 of 17...
Page 15
Set the RSSI CAS Threshold to at least 10 dB higher than the measured “own” RSSI level (for example if the measured “own” RSSI level was -120dBm, set the RSSI CAS Th ON to -110dBm or higher). 8A535X03 Rev. Preliminary-00 Page 15 of 17...
The PWR LED is flashing alternatively with the VSWR indicator when an error is found in the EEPROM of the OCR VSWR The VSWR LED is on when an excessive reflected power is detected on the Tx port 8A535X03 Rev. Preliminary-00 Page 16 of 17...
90% humidity @ 50 °C (122°F) Operating Temperature Range -30 to +60°C (-22 to +140°F) Dimensions [H x D x W] 260 x 225 x 75 mm (10.25” x 8.86” x 2.95”) Weight 4.09 kg (9 lb) 8A535X03 Rev. Preliminary-00 Page 17 of 17...
