Futurecom Mobexcom P25 Installation & Programming Manual page 75

Field Name
Private Call Hang 1-30 sec
Timeout
Disable
Enable /
Master/Slave
Disable Check
Processing Box
Disable M/S Enable /
Proc. On Analog Disable Check
VR channels Box
Enable BL for
Enable /
OSP Voice
Disable Check
Comm. and Heart Box
Beat
Enable BL for Enable /
ISP Voice Comm.
Disable Check
Box
Permanent Enable /
Master Status Disable Check
Enabled Box
Permanent Enable /
Master Control Disable Check
Disabled Box
Heart Beat 3-60 sec
Interval
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Range
Once a Private Call has been
established between two Local PSUs,
the DVR maintains the Private Call
between PSU PTTs for the duration of
this timer. If no PSU activity is detected
for the duration of this timer, the DVR
cancels the Private Call and is ready for
servicing other calls. Must be set to
match the PSU setting.
Enables / Disables the Primary /
Secondary Processing globally.
Enables / Disables the Primary /
Secondary processing on analog
channels only.
Enables / Disables the dynamic phase of
the Busy Lockout Algorithm for Outbound
Voice calls and sending of Heart Beats.
Enables / Disables the dynamic phase of
the Busy Lockout Algorithm for Inbound
Voice calls.
If this box is checked the DVR will
always be forced into Permanent Primary
State.
If this box is checked the DVR status can
not be changed to Permanent Primary by
pressing the VRS button on the Control
Head of the MSU.
Determines the time intervals at which a
Primary or Permanent Primary DVR
transmits Heart Beat messages to all
other DVRs in the area.
TM
5000 (O3 or O5) or XTL
Description
TM
2500 (M5)
8M083X01 Rev. 16
6881013Y39
Notes
Affects Private Calls
between Local PSUs
only.
The DVRS handling of
Private Calls between
Local and System PSUs
is based on the Timeout
settings of the P25
System.
Refer to the Primary /
Secondary Operation
Paragraph of this
Document.
If M/S is disabled on
analog channels, the
BL must be enabled or
else there will be no
simulcast prevention
processing.
Refer to the Primary /
Secondary Operation
Paragraph of this
Document.
Applicable to both
Analog and Digital DVR
Mode.
Refer to the Primary /
Secondary Operation
Paragraph of this
Document.
Applicable to both
Analog and Digital DVR
Mode.
The Default setting is
Disabled. Programming
more then one DVRS
as a Permanent
Primary in a given
system may result in
interference and loss of
communications.
The Default setting is not
checked i.e. User Control
is allowed.
Refer to the Primary /
Secondary Operation
Paragraph of this
Document.
'Heart Beat' messages
are part of the Static BL
Algorithm Phase and are
transmitted on the DVR
Rx frequency.
Page 39 of 79
