Field Name
Display Enable /
PTT ID Disable check
box.
TG ID
Hang Time 0-5 sec
DVR Active
Warning Tone 0-255 sec
Interval
Network Status
Reporting
0-255 sec
Interval
Encrypted
Digital
Analog
Clear
Outbound Audio
Warning Tones
on Analog VR CH
MDC Decode
0-2550 ms
Delay Time
PSU Affiliation
0-72 hrs
Timeout
None
Microphone TPS
Leading
Signaling Trailing
Both
Disabled
PPI Timing
500-10000ms
Enabled (box
Trunking Status checked) /
Send Enabled
Disabled (box
unchecked)
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Range
Enables / Disables the display of
Portable PTT ID and TG ID on the
Control Head.
Outbound calls TG ID is displayed (when
enabled) during proxied calls as well.
Determines the hang time during which
the ID remains displayed after the call
has ended.
When the DVR is in either Local or
System Mode, it can be programmed to
sound "DVR Active" Tones in the MSU
Speaker. This field specifies the repeat
interval between those tones.
Determines the intervals for sending
Trunking Network
(Failsoft, Out of Range or Site Trunking)
as well as 'Local Mode' Indication to the
Local PSUs.
Specifies the DVR repeat type when P25
Encrypted Outbound Calls are received
by the MSU and an Analog DVR channel
is selected.
Recommended setting is 1000ms (PSU
MDC pretime must be set to 700-
800ms). The
emergency retries for the duration of the
timer to allow proper processing of a
decoded MDC1200 emergency to the
system and sending of emergency ACK
to the PSU.
Determines the time a PSU ID will be
kept in the DVRS affiliation table without
detecting any activity from the PSU. After
the timer
deregisters the PSU and sends a
deregistration request to the system.
Specifies the type of TPS signaling sent
by the DVR to the Local PSUs upon
MSU Microphone PTT while the DVR is
on a TPS channel.
When enabled (Simplex Analog DVR
channels only), the DVR will periodically
interrupt transmissions during System
outbound calls and check for PSU
activity. If PSU activity is detected, the
DVR will drop the outbound call repeat
and give higher priority to the PSU
Inbound call.
When enabled – every time the DVRS
mode is
LOCAL), the DVR requests the MSU to
send a Status message 1, 2 or 3 to the
Dispatcher to notify of the DVR mode
change. The mode change can be
triggered by Control Head button press,
AVRA or remotely.
TM
5000 (O3 or O5) or XTL
Description
Status messages
DVR ignores PSU
has expired, the DVRS
changed (OFF-SYSTEM-
TM
2500 (M5)
8M083X01 Rev. 16
6881013Y39
Notes
Applicable to Digital
Mode only.
Applicable to Analog
Mode only.
Applicable to Analog
Mode only.
Recommended setting
should match that of the
'Affiliation Inactivity
Timeout' of the System
(default is 12 hrs).
Applicable to TPS DVR
Channels only.
Applicable to Simplex
Analog DVR channels
only.
Applicable to P25
Trunking Systems only.
Console must be
programmed as follows:
Status 1 = OFF mode
Status 2 = LOCAL mode
Status 3 = SYSTEM
