Appendix 12 – Accessories

Antennas

Order Code
HAD4006A
HAD4007A
HAD4008A
HAD4009A
HAE6012A
HAE4003A
HAE4004A
HAF4016A

Cables

Order PN
Code
DDN9028 7W083X05-01
DDN9029 1W083B09-01
DDN9030 1W083A01-01
DDN9031 7W083X06-01
DDN9034 7W083X17-01
DDN9032 7W083X09-01
DDN9033
7W083X16-01
DDN9025 USBAB99
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Freq. Band
[MHz]
136-144 Roof / Trunk Mount
144-150.8 Roof / Trunk Mount
150.8-162 Roof / Trunk Mount
162-174 Roof / Trunk Mount
380-433 Roof / Trunk Mount
450-470 Roof / Trunk Mount
470-512 Roof / Trunk Mount
764-870 Roof / Trunk Mount
Length
3ft DVR-to-
MSU
Custom lengths available – up to 25ft.
3ft Replaces 1 if a Siren is to be interfaced to the MSU.
- DVR Power Cable
2.5ft Options Cable.
3ft MSU to In-Band Filtering RF Cable
1ft RF switch option cable
3ft DVR to In-Band Filtering RF Cable
10ft USB DVR Programming / Re-flashing Cable
TM
5000 (O3 or O5) or XTL
Type
Notes
Control Cable.
TM
2500 (M5)
8M083X01 Rev. 16
6881013Y39
Gain
dBd
0 (Unity)
0 (Unity)
0 (Unity)
0 (Unity)
0 (Unity)
0 (Unity)
0 (Unity)
0 (Unity)
